Key Features
40 mm Thermally Broken Aluminium Panels:
Constructed from insulated aluminium frames with a continuous thermal break, ensuring minimal heat transfer and condensation risk.
ISO Package for Enhanced Performance:
Includes plastic track insulation, plastic end caps, and plastic top/bottom profiles — critical for maintaining thermal separation.
25% Better Thermal Efficiency:
Matching the insulation standard of the A40 ISO, with significantly better U-value than non-ISO versions.
Flexible Glazing Options:
Acrylic, polycarbonate, safety glass, insulated aluminium panels, and decorative inserts for customised aesthetics and daylight control.
Architectural Integration:
Standard anodised finish (E6EV1), with optional RAL powder coating to match the building façade.
CE Certified Safety
Finger protection is fitted as standard, in compliance with European safety norms.
Guide Systems (Lifting Options)
Standard lift
High lift
Vertical lift
Low headroom (rear or front mounted spring system)
Inclined tracks and custom configurations available
Each door is equipped with finger protection as standard, regardless of size or height, ensuring a safe operating environment for users. Includes ISO track insulator for improved insulation at installation level.
Applications
The AMTR A40 ISO is is especially suited for:
Automotive showrooms
Heated or air-conditioned commercial buildings
Fire stations and emergency facilities
Glass façades with thermal requirements
Public buildings requiring visual transparency and insulation
Its robust design and high insulation properties make it an excellent choice for facilities requiring energy efficiency, safety, and durability.
Technical Specifications
Technical data | Specification |
|---|---|
Panel Thickness | 40 mm |
Thermal Break | Yes (with ISO package components) |
Panel structure | Thermally broken aluminium section with filling |
Frame Material | Anodised aluminium (E6EV1) |
Standard Finish | Anodised, optional RAL powder coating |
Panel filling | ALU expanded metal, perforated aluminium sheet, smooth RAL filling of your choice |
Glass options | Acrylate, PRO-TEC, opal, pinspot, poly, safety glass |
Finger guards | Yes (standard) |
Available Panel Heights | Custom – determined per project |
Max. Door Width / Height | Made to measure (project-specific) |
Compatible Drive Systems | Manual, chain hoist, or electric (Pro-Line drive) |
Optional Features
Pass door with standard or low sill
Safety features: spring break safety, cable break device, slack cable detection, safety edge or light curtain
Mixed panel layouts (e.g. glazed top and steel bottom section)
Reinforced bottom profiles for high-contact zones
