• Self-repairing curtain system for uninterrupted operation

• Designed for cold storage and controlled temperature environments

• Opening speed up to 2.0 m/s

• Insulated PVC curtain (U = 3.7 W/m²K)

• Suitable for indoor and outdoor installation

• Wind resistance up to Class 3 (EN 12424)

• Low-maintenance and energy-efficient operation

AMTR Cold - high-speed door for cold storage environments

AMTR Cold is an industrial high-speed roll-up door designed for facilities where stable temperature conditions and continuous operation are required. The door features a flexible self-repairing PVC curtain that automatically reinserts into the side guides after accidental impact, allowing immediate resumption of operation without manual intervention.

The curtain is constructed as a multi-layer system combining PVC with an additional insulation layer, achieving a total thickness of approximately 5 mm and a thermal performance of U = 3.7 W/m²K. This helps maintain stable internal temperatures while reducing energy losses in temperature-controlled environments.

The door is powered by an inverter-controlled drive system with absolute encoder positioning, ensuring smooth and precise movement even in high-frequency operation. Opening speeds of up to 2.0 m/s improve traffic flow and operational efficiency.

AMTR Cold supports maximum dimensions up to 4500 mm in width and 5000 mm in height, with wind resistance up to Class 3 (EN 12424). The system is suitable for both indoor and outdoor use and can be adapted for operation in lower temperature conditions.

Equipped with a 3-phase motor with active brake (IP55) and an IP67 multibeam safety light barrier, the door complies with EN 12604 and EN 12453, ensuring safe and reliable performance in industrial environments.

APPLICATION

• Cold storage rooms

• Food processing facilities

• Temperature-controlled warehouses

• Logistics and distribution centres

• Production areas requiring thermal stability

• Internal industrial transport zones
