amtr-foodline. High-Quality Loading Dock Equipment – Full Product Range

AMTR FoodLine

High speed doors

AMTR FoodLine

AMTR FoodLine is a self-repairing roll-up door built for environments with strict hygiene requirements, such as food production, cleanrooms, and cold storage. Its stainless steel frame and smooth design prevent buildup of dust and liquids, allowing easy cleaning and full washdown. With opening speeds up to 2.5 m/s and a tested lifespan of over 1 million cycles, it ensures quick, energy-efficient access while reducing contamination risk. The patented sliding system with self-lubricating guides enables quiet, low-maintenance operation. Available with FDA-approved PVC options and antistatic or translucent curtain materials, AMTR FoodLine combines hygiene, speed, and durability in one reliable system.

AMTR FoodLine

High speed doors

AMTR FoodLine

High speed doors

AMTR FoodLine

High speed doors

AMTR FoodLine

Opening speed up to 2.5 m/s
Self-repairing system
Oil-free
Water drain
Gravity technology
Washable

AMTR FoodLine – high-speed hygienic door for food and clean environments

AMTR FoodLine is a self-repairing roll-up high-speed door engineered for the strict hygiene standards of the food industry. Its stainless steel frame and smooth surfaces are designed to prevent the accumulation of dust, liquids, and contaminants, allowing full washability and compliance with food-grade requirements.

Operating at speeds up to 2.5 m/s and tested for over 1 million cycles, the AMTR FoodLine ensures fast, reliable access while minimizing energy loss and cross-contamination between zones. Its patented self-lubricating sliding system and reinforced PVC curtain guarantee smooth, quiet operation with minimal maintenance.

Available with FDA-certified PVC options and antistatic or translucent materials, it is suitable for food production areas, cleanrooms, cold storage, supermarkets, and pharmaceutical environments. With IP-rated components and optional safety upgrades, AMTR FoodLine is built for safety, efficiency, and hygiene.

APPLICATION

Food and agriculture industry
Large retailers
Chemical
Pharmaceutical
General industry

Technical data	Specification
Maximum dimensions	W 6500 mm x H 6500 mm
Opening speed	Up to 2.5 m/s
Cycle test	1 000 000
Wind resistance	3000 x 3000 - Class 3 5000 x 5000 - Class 2
Structure	Not self-supporting
Curtain	Standard: PVC curtain fabric 900 gr/m² Optional: Translucent 35/40% FDA (white) Antistatic
Frame/ motor cover hood	Standard: Stainless Steel 441 Optional: Stainless Steel 304/316
Guides	Patented sliding system with high density Polyzene self-lubricant equipped of sliding zipper directly on curtain.
Control panel	Standard: PVC box (300 x 400 x 150 mm) Optional: Stainless Steel Powder coated steel box IP54 (300 x 500 x 150 mm)
Power supply	1-ph, 230V max 16A 3-ph, 400V max 10A 3-ph, 230V max 16A
Wiring	Plug and Play system IP65
Safety	Standard: Photocells set IP65 Anti-jam sensor reverse Optional: WiFi safety edge IP65 Multi ray light curtain barrier H 2500 IP67
Emergency opening	Standard: Hand crank Optional: Chain system UPS battery
Advising operative temperature	Operating till -30 C° with heating kit added. Not apt to be installed in negative/positive temperature.
Standard PVC curtain colors	RAL 9005, RAL 9010, RAL 1015, RAL 1003, RAL 2004, RAL 3002, RAL 6026, RAL 6018, RAL 7042, RAL 7037, RAL 7035, RAL 8017, RAL 9006, RAL 5012, RAL 5002, RAL 5010, RAL 7016, RAL 7038
