AMTR RapidPro

AMTR RapidPro

High speed doors
AMTR RapidPro

AMTR RapidPro is a reliable high-speed roll-up door built for intensive use in industrial settings, both indoors and outdoors. Its self-repairing curtain system automatically resets after impact, reducing downtime and maintenance. Equipped with a direct-drive motor and inverter control, it reaches speeds up to 2.5 m/s (optionally 3 m/s) and handles over 200 cycles per hour. The door is wind-resistant up to Class 4 (EN 12424), making it ideal for high-traffic zones where fast, secure closure is essential. With a reinforced PVC curtain, optional vision panels, and maintenance-free side guides, AMTR RapidPro delivers long-lasting performance for warehouses, logistics hubs, and manufacturing environments.

AMTR RapidPro

AMTR RapidPro

High speed doors
AMTR RapidPro

AMTR RapidPro

AMTR RapidPro

High speed doors
AMTR RapidPro

AMTR RapidPro

AMTR RapidPro

High speed doors
AMTR RapidPro


  • Opening speed up to 3 m/s

  • Self-repairing system

  • Wind resistance up to Class 4

  • Hermetic

  • Gravity technology

  • Sealing system

AMTR RapidPro – high-performance self-repairing roll-up door

AMTR RapidPro is a versatile high-speed roll-up door designed for demanding industrial environments. Suitable for both indoor and outdoor applications, it combines speed, safety, and durability in one intelligent system.

Thanks to its self-repairing curtain technology, the door automatically resets itself in case of accidental impact, minimizing downtime and maintenance. The direct-drive motor with absolute encoder ensures smooth and precise operation, while the inverter control system allows opening speeds of up to 2.5 m/s (optional 3 m/s) and over 200 cycles per hour.

Engineered to withstand wind loads up to Class 4 (EN 12424), AMTR RapidPro is ideal for high-traffic areas where fast access and airtight sealing are crucial. The flexible PVC curtain, optional transparent windows, and self-lubricating side guides ensure long-term reliability with minimal service requirements.

Perfect for warehouses, production facilities, food processing areas, and logistics centers, AMTR RapidPro offers robust performance with a focus on operational continuity and safety.


APPLICATION

  • Industry

  • Agriculture

  • Chemical

  • Logistics

  • Automotive

  • Sterile environments


Technical data

Specification

Maximum dimensions

W 8000 mm x H 8000 mm

Functioning

Automatic

Opening speed

Standard:

  • Up to 2.5 m/s

Optional:

  • Up to 3 m/s

Cycles per hour

> 200

Cycle test

1 000 000

Wind resistance

Up to Class 4 EN 12424

Wind speed during opening

< 20 m/s (60 km/h)

Soundproofing

15 dB Rw (ISO 717)

Water resistance

0,11 kPa for door closed Class 3 - EN12426

Curtain

Standard:

  • PVC curtain fabric 900 gr/m²

Optional:

  • Translucent 35/40%

  • FDA (white)

  • Antistatic

  • Insulated

Transom

Standard:

  • back side 20/10 galvanized steel and front cover 15/10 galvanized steel.

Optional:

  • powder coated 180 micron

Guides

Self-lubricant guide with sealing gasket, no service is required.

Side columns

Extruded black polyethilene profile (1’000’000 molecules)

Power supply

  • 3-ph, 3-230V

  • 3-ph, 3-400V

Safety

  • Safety edge Wireless transmission 433

  • Light barriers

Advising operative temperature

-10°C to +70°C

Standard PVC curtain colors

RAL 9005, RAL 9010, RAL 1015, RAL 1003, RAL 2004, RAL 3002, RAL 6026, RAL 6018, RAL 7042, RAL 7037, RAL 7035, RAL 8017, RAL 9006, RAL 5012, RAL 5002, RAL 5010, RAL 7016, RAL 7038

Insulated PVC curtain colors

RAL 9010, RAL 1003, RAL 2004, RAL 3002, RAL 7035, RAL 5002


AMTR RapidPro is a reliable high-speed roll-up door built for intensive use in industrial settings, both indoors and outdoors. Its self-repairing curtain system automatically resets after impact, reducing downtime and maintenance. Equipped with a direct-drive motor and inverter control, it reaches speeds up to 2.5 m/s (optionally 3 m/s) and handles over 200 cycles per hour. The door is wind-resistant up to Class 4 (EN 12424), making it ideal for high-traffic zones where fast, secure closure is essential. With a reinforced PVC curtain, optional vision panels, and maintenance-free side guides, AMTR RapidPro delivers long-lasting performance for warehouses, logistics hubs, and manufacturing environments.
