Key Features

Enhanced 40 mm Insulated Panels:

Steel sandwich panels with integrated thermal break, filled with CFC-free, fire-retardant polyurethane foam for optimal insulation.

25% Higher Thermal Performance:

Compared to the standard T40, the T40 ISO achieves a 25% better U-value, thanks to additional thermal insulation components:

• Plastic end caps

• Plastic top and bottom profiles

• Double side seals

• Track insulator

Durable Construction:

Outer and inner skins made of 0.5 mm galvanized steel, resistant to wear and weather conditions.

Surface Finish:

Stucco-textured with horizontal lining

• Interior: RAL 9002

• Exterior: RAL 9016, RAL 9001, RAL 9006, RAL 9007, RAL 9043, RAL 9005, RAL 8022, RAL 6007, RAL 5010, RAL 3000, RAL 9002, RAL 1015, RAL 6005, RAL 7035

Customization Options:

• Vision panels or full glazing

• Integrated pedestrian door

• Electric or manual operation

• Various lifting track systems

Guide Systems (Lifting Options)

• Standard lift

• High lift

• Vertical lift

• Low headroom (rear or front mounted spring system)

• Inclined tracks and custom configurations available




All track systems are engineered for smooth and quiet operation, with long-life torsion springs and optional corrosion-resistant components.

Applications

The AMTR T40 ISO is ideally suited for a wide range of industrial applications, including:

• Logistics centers and warehouses

• Production halls with internal climate control

• Cold storage and food processing facilities

• Buildings aiming to reduce heating or cooling energy loss

Thanks to its superior insulation system, the AMTR T40 ISO is especially suited for buildings with strict energy efficiency requirements or high internal climate control standards.

Technical Specifications
