  • Robust and reliable steel structure

  • Quick, safe loading

  • Optimising the handling process

  • Effective protection against impact and damage

  • Improved working comfort

  • Easy installation

  • Possibility to adapt the product to customer requirements


GENERAL INFORMATION

The primary function of the AMTR-S heavy-duty safety bollards is to protect loading and unloading zones, doors, walls, shelves, machinery and everything in the vicinity. Suitable for heavy loads and protection of working areas. They are an excellent alternative to other solutions when it comes to marking out traffic routes in the warehouse.

CHARACTERISTICS

  • painted in RAL 1023,

  • optionally galvanised or painted with two 100 mm wide black stripes,

  • all posts are equipped with a mounting kit.


TYPES OF BOLLARDS

AMTR-S M1 BOLLARD

This model has a diameter of 134 mm and a wall thickness of 3.2 mm. It is a suitable solution when using panel vans. This type of post works well near walkways and openings at ramps or doors.

AMTR-S M1 Model

Nominal height

Diameter

Wall thickness

AMTR-S-800-M1

800 mm

134 mm

3,2 mm

AMTR-S-1000-M1

1000 mm

134 mm

3,2 mm

AMTR-S-1200-M1

1200 mm

134 mm

3,2 mm

AMTR-S-1500-M1

1500 mm

134 mm

3,2 mm


AMTR-S M2 BOLLARD

This model has a diameter of 159 mm and a wall thickness of 4 mm. It is a suitable solution when using forklifts. This type of billard works well near openings where dock levellers are used for loading and unloading.

AMTR-S M1 Model

Nominal height

Diameter

Wall thickness

AMTR-S-800-M2

800 mm

159 mm

4 mm

AMTR-S-1000-M2

1000 mm

159 mm

4 mm

AMTR-S-1200-M2

1200 mm

159 mm

4 mm

AMTR-S-1500-M2

1500 mm

159 mm

4 mm


AMTR-S M3 BOLLARD

This model has a diameter of 219 mm and a wall thickness of 5 mm. It is a suitable solution for the entry of cars into the building. This type of bollard works well near openings where dock levellers are not used for loading and unloading.

AMTR-S M1 Model

Nominal height

Diameter

Wall thickness

AMTR-S-800-M3

800 mm

219 mm

5 mm

AMTR-S-1000-M3

1000 mm

219 mm

5 mm

AMTR-S-1200-M3

1200 mm

219 mm

5 mm

AMTR-S-1500-M3

1500 mm

219 mm

5 mm
